Range of luminaires for various urban applications

LensoFlex®2: high performance photometry, comfort and safety

FutureProof

Maximised savings in energy and maintenance costs

Aesthetic design

High-quality finishing

ThermiX®

The Piano range of luminaires is equipped with second generation LensoFlex®2 photometric engines. They offer a high-performance photometry specifically adapted to lighting urban applications.

Furthermore, the high-quality finishing and aesthetic design of the Piano complements and enhances any landscape.

This range was developed to incorporate 3 different sizes of luminaire, a wall bracket and a rear bracket version so that streets, side-streets and large pavements can be lit using the same luminaire design.

This winning combination of performance, design and flexibility makes it perfect for lighting streets, pedestrian areas, parks and bike paths. In short, the Piano family offers towns and cities the ideal tool to improve lighting levels, generate energy savings and reduce their ecological footprint.

Design: Michel Tortel

Key advantages

Piano MINI MIDI MAXI

Recommended installation height 3.5 to 12m / 11 to 40

Typical luminaire output flux (range)

1,700 to 6,600lm

3,300 to 15,200lm

11,000 to 21,200lm

Power consumption 18.2W to53.5W 34.5W to

125W 113W to 160W

Colour temperature Warm, neutral or cool white

Nominal voltage 220-240V / 120-277V / 347-480V50-60Hz

Surge protection 10kV

Characteristics

Main applications

URBAN & RESIDENTIAL

STREETS

LARGE AREAS

ROADS & MOTORWAYS

BIKE & PEDESTRIAN

PATHS

SQUARES & PEDESTRIAN

AREAS

CAR PARKS

BRIDGES RAILWAY STATIONS &

METROS

IK 07 IK 08

IP 66

69

ROAD
