Characteristics

Electrical information

Electrical class EU class I

Nominal voltage 198-264V 50Hz

Power factor > 95% at full load

Surge protection 10kV / 10kA

Electromagnetic compatibility (EMC)

SANS 55015:2013/A1:2015, SANS 61000-3-2:2014, SANS 61000-3- 3:2013, SANS 61547:2009, SANS 62493:2015

Optical information

LED colour tempera- ture

4000K (Neutral white 840)

Colour rendering index (CRI)

≥ 80 (Neutral white 840)

Upward Light Output Ratio (ULOR)

0%

Standard optic 1440

Operating conditions

Operating temperature range (Ta)

-30°C up to +40°C (*)

(*) Depending on the luminaire inclination and driving current and only applicable for outdoor use. For more details, please contact us.

Lifetime of the LEDs @ Tq 25°C

For all versions 80,000h - L70B10

Lifetime of the Driver @ Tq 25°C

For all versions 100,000h ≤10% failure rate

General information

Recommended installation height

Up to 12m

FutureProof Easy replacement of the photometric engine and electronic assembly on-site

Driver included Yes

ROHS compliant Yes

Testing standard SANS 60598, SANS 62262

Housing and finish

Housing Marine grade high-pressure die-cast aluminium (EN 1706 AC-44300)

Optic PMMA

Protector Tempered glass

Housing finish Unpainted aluminium

Tightness level IP 66

Impact resistance Up to IK 08

Access for mainte- nance

Door with screws enables access to the photometrical engine and electronic compartment

Dimensions and mounting

AxBxC (mm) 575x375x82

Weight (kg) 10

Aerodynamic resis- tance (CxS) (m2)

0.1725

Mounting Standard: Stirrup enabling adjustable inclination on-site

Optional: Wall- or pole mounted

A

B C

Ø9mm

120mm

33 m

m

8 2m

m

6 0 m

m

Ø21.5mm

132
