Characteristics

General Information

Recommended installation height

4m to 10m

Components included

Solar module Battery enclosure Battery Charge controller Luminaire

Autonomy days 2-4 days

System operating voltage

12V DC

Geographical location Designed and optimised for various locations

Weight (kg) 100 (excludes pole)

Remote monitoring Optional

Wind speed rating 144km/h

Aerodynamic resistance (CxS)

1.18m2 at 40° panel rake angle, including the side mounted battery box

Material

Battery enclosure Mild steel, e-coated (special automative anti-corrosive marine grade dip process coating) and epoxy powder coated

Linear low-density polyethylene (LLDPE)

Brackets and fixation clamps

Hot-dipped galvanised mild steel

Solar module fixation Extruded aluminium

Solar module Extruded aluminium

Tempered glass

Pole Hot-dipped galvanised mild steel

Solar Module

Technology / Rated lifetime

Polycrystalline photovoltaic module: 25 years / 80%

Peak rated wattage 160-260W

Robustness Hail and corrosion resistant

Battery

Technology / Expected lifetime

Lead-based AGM: 4-6 years

Lithium: 5-7 years

SuperCapacitor: Up to 20 years

Weight per unit Lead-based AGM: ±30kg

Lithium: 3-12kg

SuperCapacitor: 8kg

Maintenance free Yes

Charge Controller

Charge algorithm Maximum Power Point Tracking (MPPT)

Rated lifetime 20 years

Integrated data logger Yes: Up to 1 year

Integrated dawn/dusk switch

Yes

LUMINAIRE

Housing and finish

Housing ZIYA-E - UV-stabilised, calcium-filled Polypropylene

ZIYA-2 - Marine grade aluminium (EN 1706 AC-44300)

Protector High-impact polycarbonate

Housing finish ZIYA-E - Polypropylene (light grey)

ZIYA-2 - Unpainted aluminium

Tightness level IP 65

Impact resistance IK 10

Optical information

LED colour temperature

4000K (Neutral white 740)

Colour rendering index (CRI)

≥ 70 (Neutral white 740)

Upward Light Output Ratio (ULOR)

≤ 1.5%

Operating conditions

Operating temperature range (Ta)

ZIYA-E: -20°C up to +35°C (*)

ZIYA-2: -20°C up to +40°C (*)

(*) Depending on the luminaire inclination and driving current. For more details, please contact us.

Lifetime of the LEDs @ Tq 25°C

For all versions 50,000h - L70B10
