Characteristics

General information

Recommended installation height

4m to 12m Please note: We have a complete product range available. For products catering for higher installation heights, please consult us.

Driver included Yes

ROHS compliant Yes

Testing standard SANS 60598, SANS 62262

Housing and finish

Housing Marine grade high-pressure die-cast aluminium (EN 1706 AC-44300)

Optic Acrylic PMMA

Protector Glass

Polycarbonate - clear

Polycarbonate - opaque

Housing finish Pearl Light Grey (RAL 9022), Textured finish

Tightness level IP 66

Impact resistance Glass: IK 07

High-impact polycarbonate: IK 10

Dimensions and mounting

AxBxC (mm) 389x389x167

Weight (kg) 5

Standard mounting Eyebolt for suspension chain

Electrical information

Electrical class EU class I

Nominal voltage 198-264V 50Hz

Power factor > 95% at full load

Surge protection 10kV / 10kA

Electromagnetic compatibility (EMC)

SANS 55015:2013/A1:2015, SANS 61000-3-2:2014, SANS 61000- 3-3:2013, SANS 61547:2009, SANS 62493:2015

Control options 1-10V

DALI

Optical information

LED colour temperature

4000K (Neutral white 740)

Colour rendering index (CRI)

≥ 70 (Neutral white 740)

Upward Light Output Ratio (ULOR)

0%

Standard optic 4010

Operating conditions

Operating temperature range (Ta)

-30°C up to +45°C (*)

(*) Please note: ECOBAY 210W version up to +35°C

Lifetime of the LEDs @ Tq 25°C

For all versions 100,000h - L70B10

Lifetime of the driver @ Tq 25°C

For all versions 100,000h ≤10% failure rate

C

B

A
