Construction Details The luminaire consists of a pressed metal ceiling trim, reflector, ceiling brackets and reinforced luminaire frame Available in Eco or High-efficiency version Designed to operate LED light sources of up to 23W in an ambient temperature (Tq) environment of up to 35˚C, without reducing the useful lifetime of 50 000 hours (Eco) or 60 000 hours (High-efficiency), at a lumen depreciation of not more than 30% (L70) The easy-fixing ceiling brackets are made of spring steel to ensure rigid and positive mounting in the ceiling, eliminating any sagging of the luminaire Effective high-power LED, 3000K or 4000K, at a colour rendering index ≥80 The 99.9% pure aluminium reflector is made from pressed grade 1050 aluminium alloy

Dimensions in mm

Standard version Surface mount version

12 0 ˚ 51 .5

Cable entry Hole ø21

P.C.D.189 Mounting Hole ø7

120 ˚

Top view Side view

22 5

ø238

Light Distribution

Intensity Distribution

cd klm

RONDO LED

600

800

1000

30˚

400

Certification The luminaire bears the SANS 60598-2-1 safety mark.

Electrical Components It is suitable for operation with the specified rating of the lamp on a 230V +3%/-10% 50Hz single phase system. Mains connections are by means of a suitable screw terminal block. The downlight is supplied with 6A plug-top on 3m cabtyre. The luminaire is power factor corrected to ≥0,9.

205-220 mm ø232

15 4

(2 00

0 Lu

m en

)

12 3.

5 (1

00 0

Lu m

en )
