Characteristics

General information

Recommended installation height

4m to 12m

Driver included Yes

ROHS compliant Yes

Testing standard SANS 60598, SANS 62262

Housing and finish

Housing Marine grade high-pressure die-cast aluminium (EN 1706 AC-44300)

Gear compartment Glass filled nylon

Optic Acrylic PMMA

Protector Glass

High-impact polycarbonate (optional)

Housing finish Pearl Light Grey (RAL 9022), Textured finish

Tightness level IP 66

Impact resistance Glass: IK 07

High-impact polycarbonate: IK 10

Access for maintenance

Easy access to the gear compartment by means of a hinging mechanism

Dimensions and mounting

AxBxC (mm) 468x468x163

Weight (kg) 7.4

Standard mounting Hook for suspension chain

Electrical information

Electrical class EU class I

Nominal voltage 198-264V 50Hz

Power factor > 95% at full load

Surge protection 10kV / 10kA (optional)

Electromagnetic compatibility (EMC)

SANS 55015:2013/A1:2015, SANS 61000-3-2:2014, SANS 61000- 3-3:2013, SANS 61547:2009, SANS 62493:2015

Control options DALI or 1-10V

Optical information

LED colour temperature

4000K (Neutral white 740)

Colour rendering index (CRI)

≥ 70 (Neutral white 740)

Upward Light Output Ratio (ULOR)

0%

Standard optic 4130

Operating conditions

Operating temperature range (Ta)

-30°C up to +35°C

Lifetime of the LEDs @ Tq 25°C

For all versions 100,000h - L70B10

Lifetime of the driver @ Tq 25°C

For all versions 100,000h ≤10% failure rate

C

B

A

For the OMNISTAR-MAXI ordering information, please refer to the OMNISTAR MIDI/MAXI brochure.
