0˚/180˚

SERIES 300

60˚

90˚

30˚

0˚

cd/klm200300 100400500600

15˚

45˚

75˚

Light Distribution

180°

90°

0°

270°

Nominal flux (lm)

(*)

Power consumption

(W)

Nominal efficacy (lm/W)

Luminaire output flux

(lm)

Luminaire efficacy (lm/W)

Luminaire Number of LEDs Line Current

(A) Typical Typical Typical Typical Typical

S E R

IE S 3

00

80 0.09 2500 21 116 1678 80

S E R

IE S 3

00 (E

m er

ge nc

y ve

rs io

n)

80 0.09 2500 / 250 (EM) 21 116 1678 80

Performance

Tolerance on LED flux is ± 7% and on total luminaire power ± 5% (*) The nominal flux is an indicative LED flux @ Ts 85°C based on LED manufacturer s data. The real flux output of the luminaire depends on environmental conditions (e.g. temperature and pollution) and the optical efficiency of luminaire. The type of LED used is subject to change due to the ongoing rapid progress taking place in LED technology.
