Bolt Cage (Accessory)

76

76

76

ø4

26 0

M8

45 20

0

35 m

m

60 0

80x45 Cable Entry Hole

ø63.5x3 W.T

170x50x5

6 30

0

Stubby (Accessory)

ø50 Cable Entry

30 ˚

ø142.5

3xø11

Mounting Holes

PCD 88

76

H 2

H 1

H 3

H 4

ø

* Custom height available on request (min. 650mm)

ø 137mm

H1 900mm*

H2 58mm

H3 157mm

H4 29mm

Dimensions in mm

218
