Ordering Information

Example:

ZELA 43 NW SYAV76BGR 1 NC

ID Watt LED Colour Optic Protector Spigot Colour options Surge

Protection Switching/dimming

control Other options /

accessories

ZE LA

19 23 37 43

CW Cool White

(5700K) NW

Neutral White (4000K)

SY Symmetrical

light distribution

AS Asymmetrical

light distribution

A Acrylic (IK08)

P Polycarbonate

(IK10) POL

Police version

V76 Ø76mm

bottom entry

BGR Telegrey 4 (RAL 7047),

Textured finish AK9

AKZO 900 Grey, Textured finish

MBG Mid Brunswick

Green (RAL 6005),

Textured finish BLK

Black (RAL9017), Textured finish

WHT White

(RAL 9003), Textured finish

SST Sandstone (RAL 1001),

Textured finish DGR

Dark Grey (RAL 7045),

Textured finish PLG

Pearl Light Grey (RAL 9022),

Textured finish P/O

Painted Other (RAL / Finish

[Brilliant/Matt])

1 10kV

DL Daylight switch

12V 12V solar version

NC No cable supplied

Switching/dimming control

DALI

1-10V

Optidim (DIM profile 1-5)

Solar Optipower (Profile 2)

Electrical class EU Class II

Cabtyre

4m

6m

9m

Correlated colour temperature 3000K (Warm white)

Custom Options
