Optical compartment tightness level: IP 54 (*)

Control gear tightness level: IP 54 (*)

Impact resistance (acrylic): IK 08 (**)

Nominal voltage: 198-264V - 50Hz

Electrical class: I (**)

Weight (total): Up to 14kg

Materials:

Housing: Aluminium

Diffuser: Acrylic

Standard colour: White (RAL 9003), Textured finish

LED light sources

Correlated colour temperature (CCT): Neutral white light (4000K, CRI ≥80)

Wattage: 16W - 150W

Flux: 1800lm - 17601lm

(*) according to SANS 60598 (**) according to SANS 62262

Construction Details The luminaire consists of an aluminium housing, enclosed by an acrylic diffuser. The luminaire is suspended by means of a 3-fold wire rope suspension. It is designed to operate an LED engine of up to 144W. The luminaire bears the SANS 60598 safety mark. The electronic power supply is suitable for operation with a 198-264V - 50Hz single phase system. The power factor is rated at >0,95. The efficiency is rated >89%. Electronic temperature monitoring prevents overheating of LEDs and power supply (ThermiX®).

Options Fully dimmable 0%-100% (DALI) Extra length of suspension system

Characteristics
