The top opening provides access to the gear compartment for cabling and maintenance.

The TECEO GEN2 range offers universal fixations for spigots ranging from Ø32 to Ø76mm.

TECEO GEN2 is available with NEMA or low-voltage sockets.

The inclination angle can be adjusted on-site for both post-top (0 to +15°) and side-entry (0 to -15°) configurations.

TECEO GEN2 is composed of three different parts in aluminium, with a top opening. The hinges of the top cover open 120° to provide access to the gear compartment.

TECEO GEN2 can be fitted with LensoFlex®2 photometric engines, protected by a tempered glass.

The TECEO GEN2 range offers optimised photometrical performance with a minimum total cost of ownership. This highly efficient luminaire is available in three sizes to offer towns and cities the ideal tool to improve lighting levels, generate energy savings and reduce their ecological footprint.

TECEO S, for up to 24 LEDs, has been designed for low-height applications such as residential streets, car parks and bike paths. TECEO GEN2 1, for up to 48 LEDs, is ideally suited to lighting urban roads and squares while TECEO GEN 2 for up to 144 LEDs is perfect for large roads, avenues and motorways.

The complete range is available with three different universal fixation parts adapted for post- top and side-entry mounting on various spigots (Ø32mm with adapter, Ø42-48mm, Ø60mm and Ø76mm). The inclination angle can be adjusted on-site for both post-top (0 to +15°) and side- entry (0 to -15°) configurations.

Concept
