Construction Details

The body is manufactured from injection-moulded, UV stable polycarbonate material. Mounting is facilitated through removable external stainless steel mounting brackets, which can accommodate either surface or suspension mounting. A silicon sponge gasket is fitted into a special groove in the housing. This, in conjunction with the tongue provided on the diffuser, ensures the optimal sealing of the total enclosure, thereby maintaining the IP 65 ingress protection rating.

The diffuser is manufactured from injection-moulded, UV stable polycarbonate material. The highly effective internal prisms of the diffuser ensure an optimal distribution with a transmission value of ≥91%. The diffuser is secured in place through multiple sprung stainless steel clips which ensure the integrity of the IP rating.

The electronic gear is mounted on the reverse side of the powder coated steel LED mounting plate and is accessible for maintenance. The LED modules are clipped into the diffusor, creating a protected and enclosed optical compartment within the luminaire. This will prevent any premature damage to the LEDs during installation or during maintenance.

All control gear components are removable. Mains connections are by means of a suitable screw terminal block with a wire clamping contact.

Light Distribution

VLN LED optic

200 150 50100 90

75

60

45

30 15 0

250300

90°/270°0°/180°

cd/klm
