Various colour combinations and options available

Construction Details

The luminaire consists of a head assembly containing the optics, as well as a pole base assembly containing the control gear. The pole base assembly is manufactured from glass filament wound GRP. It is designed to operate LEDs of 30W.

The bollard head assembly is manufactured from three marine grade high-pressure die-cast aluminium castings consisting of the base casting which is fixed permanently to the pole, the top casting which compresses the gasket system by three tie bars and the dome trim casting. The trim casting is held to the top casting with a special anti-twist device and one stainless steel special coded access screw. The gasket system ensures that the bollard head assembly is completely sealed from the pole base assembly to ensure that no humidity or dust from the pole assembly rises into the lamp compartment. The bollard protector is manufactured from a high temperature, non-discolouring clear impact resistant acrylic with a wall thickness of not less than 8mm. The protector is seamless and smooth on both the inside and outside.

The optical system consists of a bead blasted aluminium louvre system providing quality low-level lighting and glare control.

The control gear is incorporated inside the pole base assembly and is mounted on a 2mm stainless steel gear tray which is held to the base casting with two captive screws for ease of maintenance. It is suitable for operation with the specified rating of the light source on a 198V-277V 50Hz single phase system. All control gear components are removable and bear the relevant SABS mark. All internal wiring is Teflon® coated with protective sleeving to prevent damage by possible abrasion. All screws, bolts and metal parts are stainless steel or non-corrosive material.

Mains connections are by means of a suitable screw terminal block with a wire clamping contact.

The power factor is rated at ≥0,95.

Key Features

The bead blasted aluminium louvre system provides low-level lighting and glare control.
