Front view
19 5
341
Bottom view
105
48
Side view
Dimensions in mm
Key Features
Four fixing holes to hold the trim ring casting to the base casting
by stainless steel M5 Allen head screws, located outside the lamp
compartment.
Base casting is manufactured from high-pressure die-cast aluminium, finished both outside and inside in white epoxy powder coating for added protection and reflectivity.
Tongue provided on the base casting fits into the silicon sponge gasket seated in the diffuser, thus achieving SABS certified IP 65 protection.
Four mounting holes provided outside the lamp compartment ensure the integrity of the certified IP rating. The mounting holes are raised
2mm from the base, preventing rainwater from running over the luminaire surface, and are also offset from the main axis in order to
prevent accidental damage to conduits during the installation process.
99.98% super pure deep anodized aluminium reflector.
The grommet provided in the base casting allows the
feeding through of the Teflon® wiring supplied, thus ensuring integrity of
IP 65 rating.
It is designed to operate LEDs of up to 8W.
