Construction Details The luminaire consists of a high-pressure die-cast marine grade aluminium body with a robust clear polycarbonate diffuser and is designed to operate LEDs of up to 56W. The luminaire bears the SANS 60598-2-1 safety mark.

It is specifically designed for surface mounted applications. The body and diffuser are designed in such a way to prevent collection of dust on the accessible surface of the body, thus also preventing any grip of the luminaire. The luminaire is designed to allow entry of surface conduits via 20mm conduit threaded entries at both ends, as well as a 25mm hole in the centre of the back of the body.

A silicone sponge gasket ensures reliable IP 65 rating. The one-piece, injection-moulded polycarbonate diffuser is vandal resistant. It is secured to the body by six stainless steel Allen head screws. Tamper-proof screws with centre- pin are available upon request.

The removable gear tray is manufactured from mild steel, powder coated white to optimise luminaire efficiency. All control gear components are mounted on the gear tray. The gear tray can be removed by loosening four Allen

Optical compartment tightness level: IP 65 (*)

Control gear tightness level: IP 65 (*)

Impact resistance (polycarbonate): IK 10 (**)

Nominal voltage: 198-277V - 50Hz

Electrical class: I (**)

Weight (total): Up to 3.8kg

Materials:

Housing: Marine grade aluminium (EN 1706 AC-44300)

Diffuser: Polycarbonate

Standard colour: Pearl Light Grey (RAL 9022), Textured finish

LED light sources

Correlated colour temperature (CCT): 4000K (Neutral white 840)

Colour rendering index (CRI): ≥80

Wattage: 7W - 56W

Flux: 1060lm - 8200lm (*) according to SANS 60598 (**) according to SANS 62262

Characteristics

head screws in keyhole slots, which allow the gear tray to be relieved into a suspended position, ensuring ease of maintenance.

All control gear components are removable and bear the relevant SABS mark. All screws, bolts and metal parts are stainless steel or non-corrosive material. Mains connections are by means of a suitable screw terminal block with a wire clamping contact.

Electronic temperature monitoring prevents overheating of LEDs and power supply. Power factor ≥0,95.

Options Opaque diffuser (26W and 56W version) Fully dimmable 0%-100% (DALI, 1-10V) Emergency version Tamper-proof screw with centre-pin
