Construction Details The luminaire consists of a marine grade, high-pressure die-cast aluminium housing with a high impact resistant glass sealed to IP 66. Supplied complete with an adjustable stainless steel (304) stirrup mounting. The stirrup is manufactured from 4mm x 80mm stainless steel. Holes are provided for single or double bolt mounting.

Dimensions in mm

150

55

14 5

25

100

15 5

286

ø9 Holes for mounting

Optical compartment tightness level: IP 66

Control gear compartment tightness level: IP 66

Nominal voltage: 198-268V - 50Hz

Electrical class: I

Weight (total): 3,4kg

Correlated colour temperature (CCT): Neutral white light (4000K, CRI ≥70)

Materials: Body: Marine grade aluminium (EN 1706 AC-47300)

Protector: Impact-resistant clear glass

Standard colour: Black (RAL 9017), Textured finish

Characteristics
