Nominal flux (lm)
(*) Power
consumption (W)
Nominal efficacy (lm/W)
Luminaire output flux
(lm)
Luminaire efficacy (lm/W)
Photometry
Luminaire Number of LEDs Current
(mA) Line
Current (A) Typical Typical Typical Typical Typical
Q VA
L 32 700 0.08 2870 18 159 2700 150
Optic 4410
64 700 0.15 5740 36 159 5338 148
Performance
Tolerance on LED flux is ± 7% and on total luminaire power ± 5% (*)
The nominal flux is an indicative LED flux @ Tj 25°C based on LED manufacturer s data. The real flux output of the luminaire depends on environmental conditions (e.g. temperature
and pollution) and the optical efficiency of luminaire. The type of LED used is subject to change due to the ongoing rapid progress taking place in LED technology.
Light Distribution
300
400
200
90°/270°
4410 optic
0°/180°
cd/klm
100
0
90
60
30
120
150
180
Horizontal Illuminance
E (lx)
10 5
MH: 4.5m
Isolux H (m)
QVAL 36W Optic 4410 QVAL 18W Optic 4410
0 1H 2H 3H 4H 5H
0
1H
2H
3H
4H 1
18W 36W
0.5
2.5 5
5H
0 1H 2H 3H 4H 5H
50
10
5
MH: 3m
Isolux H (m)
QVAL 36W Optic 4410 QVAL 18W Optic 4410
0
1H
2H
3H
4H
10.5
2.5
5
25
E (lx)
18W 36W
5H
249
