ID LED Watt LED Colour Optic Colour options Surge

Protection Protector Mounting Switching/dimming

control Other options /

accessories

LE D

BA Y

M D 160

192 256

132 158 177

N Neutral White

(4000K)

4120 4130 4140

A Aluminium

finish (unpainted)

S Pearl Light Grey

(RAL 9022), Textured finish

B Black

(RAL 9017), Textured finish

O Painted Other (RAL / Finish

[Brilliant/Matt])

1 10kV

2 20kV

G Glass clear

(IK 07) P

Polycarbonate (IK 10)

/S Suspended

/U U-bracket

1-10 1-10V dimming

DALI DALI dimming

M6 Movement sensor

up to 6m M12

Movement sensor up to 12m

E1 Emergency version

(1 hour) E3

Emergency version (3 hour)

TW Through-wiring

3M(1) 3 meter cabtyre complete with

6A plug 5M(1)

5 meter cabtyre complete with

16A plug Z21/22

Zone 21/22

Ordering Information Example:

LEDBAY MD256/177N4140A1G/SE1M6DALITWZ21/22

(1) Excluding through-wire, emergency and dimmable versions

Extra treatment e-Coating for very harsh environments (casting only)

Custom Options

For the OMNISTAR-MAXI ordering information, please refer to the OMNISTAR MIDI/MAXI brochure.
